3M 86420
3M 86420 is a 0.20 mm (0.008 in) black, acrylic foam tape. This thin 3M Tape is used for bonding a wide range of materials in the electronics industry. It is designed specifically for applications with thin bond lines. It boasts superior impact resistant to meet industry drop test requirements.
- Color: Black
- Thickness: 0.20mm
- Material: Acrylic
- Liner: Polyester
- Liner Thickness:0.08 mm (3 mil)
3M 86420 Technical Data Sheet
| Attribute Name | Value |
|---|---|
| Adhesive Type | Acrylic |
| Density | 960 kg/m³ (60 lb/ft³) ¹ |
| Total Tape Thickness | 0.2 mm (8 mil) |
| Color | Black |
| Liner | Polyester |
| Liner Thickness | 0.08 mm (3 mil) |
| Primary Liner Color | Clear |
| Thickness Tolerance | ± 15 % |
3M 86420 Features
- Excellent impact resistance
- High bonding strength
3M 86420 Applications
- Used for bonding a wide range of high and low surface energy materials in the electronics industry
- Lens bonding
- LCM attachment
- Bezel bonding
- Other applications with thin bond lines
- Laptop Bezel Trim Attachment
